Material | |
---|---|
Cable End Housing | SUS 316 |
RJ45 Plug Housing | PC |
RJ45 Plug Contacts | Copper Alloy‚ Au Plating |
RJ45 Plug Shell | Copper Alloyor or Cold Roller Steel‚Ni Plating |
Cable End Rubber Pad | Silicone |
Inner Mold | PE |
Over Mold | PVC |
Technical Data | |
Insulation Resistance | DC500V±10%‚test for 1 minute and the insulation resistance should be more than 100MΩ |
Dielectric Withstanding Voltage | 500 V DC/AC peak‚ contact-to-contact‚ for 1 minute. 500 V DC/ AC peak‚ contact-to-test panel or contact-to-shield for 1 min. |
Contact Resistance | 20mΩ at 10mA Max. |
Durability | Screw type 750 cycles ‚rate of 200 cycles per hour Lock type 200 cycles ‚rate of 200 cycles per hour. |
Thermal Shock | 5 cycles at -40°C / +105°C‚ after the test‚ the function and appearance can't be impacted. |
Waterproof Test | Under 1 M water for 24 hr. |
